Series F-09130 Linear Actuators

Description

• Compact, flexible design is suitable for combustion and process control applications.
• Stepping motor stops and starts instantaneously: eliminates coast and provides precision positioning.
• High starting torque overcomes static friction.
• Impedance-protected motor is not damaged if overload stalling occurs.
• Standard 6″ range of travel.
• 30, 60, and 120 second nominal stroke times.
• 75, 150, and 300 lb. thrust ranges. Equivalent to 18.75, 37.5, and 75.0 ft. lbs.
• Operates on switched line voltage input.
• Optional handwheel.
• Optional isolated auxiliary end switch.
• Optional adjustable starting position switches.
• Available NEMA 3 (weather-resistant) housing.
• Linkage: clevis and shaft lever arm, spring link for tight closed valve applications.
